Product Summary
The LQ104V1DG21 is a color TFT-LCD module.
Parametrics
LQ104V1DG21 absolute maximum ratings: (1)Input voltage, Ta=25℃: －0.3 ～ Vcc+0.3 V; (2)+5V supply voltage, Ta=25℃: 0 ～ + 6 V; (3)Storage temperature: －30 ～ +70℃; (4)Operating temperature (Ambient): －10 ～ +65℃.
Features
LQ104V1DG21 specifications: (1)Display size: 26 (10.4") Diagonal cm; (2)Active area: 211.2(H)×158.4(V) mm; (3)Pixel format: 640(H)×480(V) pixel, (1 pixel＝R+G+B dots); (4)Pixel pitch: 0.330(H)×0.330(V) mm; (5)Pixel configuration: R,G,B vertical stripe; (6)Display mode: Normally white; (7)Unit outline dimensions: 265.0(W)×195.0(H)×11.5max(D) mm; (8)Mass: 700(max) g; (9)Surface treatment: Anti-glare and hard-coating 3H.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LQ104V1DG21 |
Sharp Microelectronics |
TFT Displays & Accessories 10.4" TFT (2 x CCFT) VGA |
Data Sheet |
Negotiable |
|
||||||
