Product Summary

The B104SN01 is a 10,4" TFT-LCD module.

Parametrics

B104SN01 absolute maximum ratings: (1)Power voltage, VCC: -0.3 to 4 VDC; (2)Input signal voltage, VLH: -0.3 to VCC+0.3 VDC; (3)Operating temperature, Top: -10 to +60℃; (4)Storage temperature, TST: -20 to +70℃.

Features

B104SN01 features: (1)power supply voltage, input voltage, VCC: 3.0 to 3.6V, 3.3V typ; current consumption, IA: 310mArms; IB: 330mArms; inrush current, IRUSH: 1500mApeak; (2)internal logic, low voltage, VIL: 0 to 0.3VCC; high voltage, VIH: 0.7VCC to VCC; (3)power ripple voltage, VRP: 100mVp-p.

Diagrams

B104SN01 block diagram
