Product Summary
The B1048N01 is a 10.4-inch LCD panel. Applications of it are: Industrial control, Medical Monitor, Machinery Equipment, DPF, LCD Media player, Portable DVD, Car Mobile media, numerical control etc.
Parametrics
B1048N01 general specifications: (1)Panel Type: TFT; (2)Active Screen Size: 10.4 inch; (3)Active area: 211.2*158.4; (4)Pixel Format: 800*600 SVGA; (5)Weight: 295 g; (6)Outline dimensions(W/H/D)mm: 236*174.3*5.6; (7)Operating temperature: 0 to 60 ℃; (8)Storage temperature: -20 to 70 ℃.
Features
B1048N01 features: (1)TFT; (2)1CCFL Lamp; (3)800x600; (4)Luminance:150; (5)Contrast ratio:250:1; (6)Visual angle:15/35/45/45.
![]() |
