Product Summary
The A035CN02 is a 3.5 inch color TFT-LCD panel.
Parametrics
A035CN02 absolute maximum ratings: (1)Power voltage, VCC: -0.3 to 7V when GND=0; AVDD: -0.3 to 7 V when AVSS=0l; VGH: -0.3 to 18 V; VGL: -18 to 0.3 V; VGH－VGL: 33V when GND=0; (2)Input signal voltage, Vi: -0.3 to AVDD+0.3V; VI: -0.3 to VCC+0.3 V; VCOM: -2.9 to 5.2 V; (3)Operating temperature, Topa: 0 to 60℃; (4)Storage temperature, Tstg: -25 to 80℃.
Features
A035CN02 features: (1)Panel Typ: a-Si TFT-LCD, panel; (2)Panel Size: 3.5 inch; (3)Resolution: 480×234; (4)Display Mode: TN, normally white, transmissive; (5)Brightness: 250cd/m2 (Typ.); (6)Contrast Ratio: 150:1 typ; (7)Response Rime: 20/30 (Typ.)(Tr/Td); (8)Viewing Angle: 40/40/10/30 (Min.)(CR≥10) (L/R/U/D); (9)Lamp Type: 4S2P; (10)Signal Interface: TFT Specific Analog RGB; (11)Input Voltage: 5/5/15/5V (Typ.)(VCC/AVDD/VGH/VGL).
Diagrams
 |
 A035 |
|
SET TEST LEAD LIGHTED |
Data Sheet |
|
|
||||||
