Product Summary

The KCG062HV1AC-A21 is a 6.2-inch industrial LCD panel suitable for Industrial control, Maintenance for Mechanic etc.

Parametrics

KCG062HV1AC-A21 absolute maximum ratings: (1)Panel Type: STN; (2)Active Screen Size: 6.2 inch; (3)Brightness(cd/m2): 160; (4)Active area: 149.8*57.4; (5)Pixel Format: 320*240; (6)Contrast ratio: 30:1; (7)Backlight: 1CCFL Lamp; (8)Input voltage: 3.3V; (9)Weight: 135 g; (10)Outline dimensions(W/H/D)mm: 174.2*73.4*7.6; (11)Operating temperature: 0 - 50℃; (12)Storage temperature: -20 - 60℃.

Features

KCG062HV1AC-A21 features: (1)STN 320×240 1CCFL backlight; (2)Luminance:160cd/m2; (3)Contrast ratio:30:1; (4)Operating temperature:0 ~ +50℃
